Technical parameters :
Rated voltage and current : AC250V/16A、AC125V/15A
Temperature range : 0~250℃
The highest environment temperature : 250℃
Rotation angle : 0-310°
Contact resistance : <50mΩ
Insulation resistance : >100MΩ
Electric strength : 2000V/0.5mA/ls
Service life : 100000times
Character :
The lock hole and knob have different size, and there are Φ4.2, M3, M4 and etc lock holes which can be choose. The size of the terminal and the angle can be made according to the customer's requirement.
